Introduction

The multifunctional Alcatel-Lucent OmniAccess® Stellar Outdoor AP1360 series access points with 802.11ax technology enables faster speeds, more capacity, and efficient airtime allocation for clients on both 2.4Ghz and 5Ghz Wi-Fi bands. This enables Access Points to better service higher density of clients, deliver more capacity for bandwidth hungry and latency sensitive voice and video clients, and provide a dependable secure network for IoT devices while increasing their battery powered lifespan. The OmniAccess® Stellar WLAN brings unparalleled experience for connectivity, coverage and performance for the modern IoT connected Enterprise. The 802.11ax high performance and rugged AP1360 series models are designed to accommodate diverse growing capacity needs of next generation Mobility & IoT enabled networks. The access points are powered with four built-in radios, dual radios 2.4Ghz/5Ghz band serving high density Wi-Fi clients, a full band radio dedicated for scanning, inherently improving network security and Wi-Fi quality. It also has an integrated Bluetooth/Zigbee radio enabling location and building automation services. The access points are IP67 rated for harsh outdoor environments, such as exposure to high and low temperatures, persistent moisture and precipitation, and industrial strength surge protection. The AP1360 series models support maximum aggregate data rate ~ 3Gbps (2.4Gbps in 5 GHz and 573Mbps in 2.4 GHz), and to support this higher capacity the access point is powered by Multigig Ethernet uplink. The AP1360 series models can be connected to the network via SFP for long distance backhaul, provides an additional downlink Ethernet interface for wired IoT device endpoint connection, catering to varied deployment options in today’s demanding outdoor environments. OmniAccess® Stellar AP1360 series support all mandatory and several optional 802.11ax features, which include DL OFDMA with up to 37 RUs, UL OFDMA with up to 37 RUs, DL MU-MIMO , UL MU-MIMO, 1024-QAM modulation and more, making tomorrows diverse digital workspaces including outdoor settings highly reliable and efficient.

Features

2.4 GHz

Y

5 GHz

Y

Maximum data transfer rate

2400 Mbit/s

Maximum data transfer rate (2.4 GHz)

573 Mbit/s

Maximum data transfer rate (5 GHz)

2400 Mbit/s

Ethernet LAN data rates

10,100,1000,2500 Mbit/s

Networking standards

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Cabling technology

10/100/1000Base-T(X)

Number of users

512 user(s)

Automatic channel selection

Y

MIMO

Y

MIMO type

Multi User MIMO

Modulation

16-QAM, 64-QAM, 256-QAM, 1024-QAM, CCK, QPSK

VLAN support

Y

Quality of Service (QoS) support

Y

Security

Security algorithms

HTTPS, WEP, WPA2, WPA3

Number of SSID supported

16

DHCP snooping

Y

Remote Authentication Dial-In User Service (RADIUS)

Y

Access Control List (ACL)

Y

Management features

Web-based management

Y

Ports & interfaces

Ethernet LAN (RJ-45) ports

2

USB 2.0 ports quantity

1

DC-in jack

Y

Power

Power over Ethernet (PoE)

Y

AC input voltage

48 V

Power consumption (typical)

64 W

Design

Product colour

White

LED indicators

Y

Antenna

Antenna type

Internal

Antenna direction type

Omni-directional

Antenna features

Integrated antenna

Antenna gain level (max)

6.48 dBi

Weight & dimensions

Width

243 mm

Depth

243 mm

Height

85 mm

Weight

2.5 kg

Operational conditions

Operating relative humidity (H-H)

10 - 90%

Operating temperature (T-T)

-40 - 65 °C

Storage temperature (T-T)

-40 - 85 °C

Logistics data

Harmonized System (HS) code

85176990
