Performance

Video input channels

256 channels

Alarm input channels

16

Alarm output channels

4

Maximum resolution

3840 x 2160 pixels

Supported resolutions

8MP,5MP,3MP,2MP(1080P),1.3MP(960P),1.0MP(720P)

Video motion detection

Yes

On Screen Display (OSD)

Yes

Audio formats supported

G.711 A-law

Video formats supported

H.264, H.264+, H.265, H.265+

Languages support

Multi

Playback modes

Forward, Slow play

Maximum frame rate

960 fps

Input bandwidth

1024 Mbit/s

Output bandwidth

1024 Mbit/s

Face detection

Yes

Wireless LAN features

Wi-Fi

No

Hard drive

Number of HDDs supported

16

Maximum storage capacity

12 TB

HDD interface

SATA

RAID support

Yes

RAID levels

0, 1, 4, 5, 6, 10

Ports & interfaces

Ethernet LAN (RJ-45) ports

2

Ethernet LAN data rates

10,100,1000 Mbit/s

HDMI output

Yes

HDMI ports quantity

4

USB 2.0 ports quantity

1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

eSATA ports quantity

1

Internal SATA ports quantity

16

eSATA

Yes

Audio output

1

RS-232 ports

1

Features

Rack mounting

Yes

LED indicators

Yes

On/off switch

Yes

Product colour

Black

Power

Power consumption (max)

250 W

AC input voltage

110 - 240 V

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

0 - 90%

Weight & dimensions

Width

440 mm

Depth

460 mm

Height

189 mm
