Performance

Maximum video resolution

3840 x 2160 pixels

Video compression formats

H.264, H.265

Audio formats supported

G.711 A-law

Video recording trigger modes

Motion detection

Video capturing speed

30 fps

Video capturing speed (PAL)

25 fps

Video capturing speed (NTSC)

30 fps

Playback resolutions supported

8MP(15FPS) 5MP(20FPS) 4MP/1080P/720P/960H(30FPS) IP 4K/4MP/1080P/720P

Channels quantity

4 channels

Product colour

Black

Playback modes

Fast Backward, Fast forward, Slow backward, Slow forward

Operating system installed

Embedded LINUX

Languages support

Multi

Maximum frame rate

120 fps

Video streaming

Yes

Audio streaming

Yes

Dual stream support

Yes

Total bandwidth

48 Mbit/s

Ports & interfaces

Video input channels

4 channels

BNC input ports

4

HDMI ports quantity

1

VGA (D-Sub) output ports

1

Audio input

4

Audio output

1

USB 2.0 ports quantity

2

RS-485 ports

1

Network

Ethernet LAN

Yes

Ethernet interface type

Fast Ethernet

Ethernet LAN (RJ-45) ports

1

Ethernet LAN data rates

10,100 Mbit/s

Hard drive

Number of HDDs supported

1

Maximum HDD capacity

12 TB

Supported HDD interfaces

Serial ATA

Power

Power supply type

DC

DC voltage

12 V

Power consumption (max)

4.7 W

DC current (max)

2 A

Weight & dimensions

Width

201 mm

Depth

300 mm

Height

48 mm

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

0 - 90%
