Design

Colour name

Black

Product type

Notebook

Product colour

Black

Form factor

Clamshell

Display

Display diagonal

33.8 cm (13.3")

Display resolution

1366 x 768 pixels

Touchscreen

N

HD type

HD

Display surface

Matt

Dual-screen

N

Processor

Processor manufacturer

Intel

Processor generation

8th gen Intel® Core™ i3

Processor model

i3-8145U

Processor frequency

2.1 GHz

Processor boost frequency

3.9 GHz

Processor family

Intel® Core™ i3

Processor cores

2

Processor threads

4

System bus rate

4 GT/s

Processor cache

4 MB

Processor cache type

Smart Cache

Processor socket

BGA 1528

Processor lithography

14 nm

Processor operating modes

64-bit

Processor codename

Whiskey Lake

Bus type

OPI

Thermal Design Power (TDP)

15 W

Configurable TDP-up frequency

2.3 GHz

Configurable TDP-up

25 W

Configurable TDP-down

10 W

Configurable TDP-down frequency

0.8 GHz

Tjunction

100 °C

Maximum number of PCI Express lanes

16

PCI Express slots version

3.0

PCI Express configurations

1x2+2x1,1x4,2x2,4x1

Memory

Internal memory

4 GB

Internal memory type

LPDDR3-SDRAM

Memory clock speed

2133 MHz

Memory form factor

On-board

Maximum internal memory

4 GB

Storage

Total storage capacity

128 GB

Storage media

SSD

Total SSDs capacity

128 GB

Number of SSDs installed

1

SSD capacity

128 GB

SSD interface

PCI Express

SSD form factor

M.2

Optical drive type

N

Card reader integrated

Y

Compatible memory cards

MicroSD (TransFlash)

Graphics

Discrete graphics card model

Not available

On-board graphics card

Y

Discrete graphics card

N

On-board graphics card model

Intel® UHD Graphics

On-board graphics card base frequency

300 MHz

On-board graphics card dynamic frequency (max)

1000 MHz

Maximum on-board graphics card memory

32 GB

On-board graphics card DirectX version

12.0

On-board graphics card OpenGL version

4.5

On-board graphics card ID

0x3EA0

Audio

Audio chip

Realtek ALC3204

Audio system

MaxxAudio Pro

Number of built-in speakers

2

Speakers manufacturer

Waves

Speaker power

2 W

Built-in microphone

Y

Camera

Front camera

Y

Front camera resolution (numeric)

0.92 MP

Front camera resolution

1280 x 720 pixels

Front camera signal format

720p

Front camera HD type

HD

Video capturing speed

30 fps

Network

Bluetooth

Y

Wi-Fi

Y

Top Wi-Fi standard

Wi-Fi 5 (802.11ac)

Wi-Fi standards

Wi-Fi 5 (802.11ac)

Antenna type

2x2

WLAN controller model

Intel Dual Band Wireless-AC 9560

Ethernet LAN

N

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

1

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

1

HDMI ports quantity

1

Combo headphone/mic port

Y

Charging port type

DC-in jack

USB Type-C DisplayPort Alternate Mode

Y

Keyboard

Pointing device

Touchpad

Keyboard language

Belgian

Numeric keypad

N

Keyboard backlit

Y

Windows keys

Y

Software

Operating system architecture

64-bit

Operating system language

Multilingual

Trial software

Microsoft Office

Operating system installed

Windows 10 Pro

Processor special features

Intel® My WiFi Technology (Intel® MWT)

Y

Intel® Smart Response Technology

Y

Intel® Identity Protection Technology (Intel® IPT)

Y

Intel® Hyper Threading Technology (Intel® HT Technology)

Y

Intel® Turbo Boost Technology

2.0

Enhanced Intel SpeedStep Technology

Y

Intel® Clear Video HD Technology (Intel® CVT HD)

Y

Intel Clear Video Technology

Y

Intel® Quick Sync Video Technology

Y

Intel Flex Memory Access

Y

Intel® AES New Instructions (Intel® AES-NI)

Y

Intel Trusted Execution Technology

N

Intel Enhanced Halt State

Y

Intel VT-x with Extended Page Tables (EPT)

Y

Intel® Secure Key

Y

Intel TSX-NI

N

Intel® OS Guard

Y

Intel Software Guard Extensions (Intel SGX)

Y

Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)

Y

Intel 64

Y

Execute Disable Bit

Y

Idle States

Y

Thermal Monitoring Technologies

Y

Processor package size

46x24 mm

Supported instruction sets

AVX 2.0,SSE4.1,SSE4.2

CPU configuration (max)

1

Embedded options available

N

Intel Virtualization Technology for Directed I/O (VT-d)

Y

Intel Identity Protection Technology version

1.00

Intel Smart Response Technology version

1.00

Intel Secure Key Technology version

1.00

Intel TSX-NI version

0.00

Intel Virtualization Technology (VT-x)

Y

Processor ARK ID

149090

Battery

Battery technology

Lithium-Ion (Li-Ion)

Number of battery cells

4

Battery voltage

7.6 V

Battery weight

220 g

Power

AC adapter power

65 W

AC adapter frequency

50 - 60 Hz

AC adapter input voltage

100 - 240 V

AC adapter output current

3.34 A

AC adapter output voltage

19.5 V

Security

Password protection

Y

Operational conditions

Operating temperature (T-T)

0 - 35 °C

Storage temperature (T-T)

-40 - 65 °C

Operating relative humidity (H-H)

10 - 90%

Storage relative humidity (H-H)

10 - 95%

Operating altitude

-15.2 - 3048 m

Operating shock

110 G

Non-operating shock

160 G

Operating vibration

0.66 G

Non-operating vibration

1.3 G

Weight & dimensions

Width

307.6 mm

Depth

204.5 mm

Height (front)

1.68 cm

Height (rear)

1.49 cm

Weight

1.18 kg

Packaging content

Manual

Y

Power cord included

Y

Other features

AC adapter included

Y

Maximum internal memory (64-bit)

4 GB
