Features

UPS topology

Line-Interactive

Output power capacity

0.65 kVA

Output power

520 W

Waveform

Sine

Input operation voltage (min)

150 V

Input operation voltage (max)

294 V

Input frequency

47/70 Hz

Output operation voltage (min)

200 V

Output operation voltage (max)

240 V

Output frequency

50/60 Hz

Automatic Voltage Regulation (AVR)

Yes

Heat dissipation

461 BTU/h

Number of input phases

1

Number of output phases

1

Efficiency

97%

Power factor

0.8

Noise level

35 dB

Ports & interfaces

AC outlet types

C13 coupler

Power plug

C14 coupler

AC outlets quantity

4 AC outlet(s)

USB port

Yes

USB port type

USB Type-B

Serial interface

Yes

Serial interface type

RS-232

Serial ports quantity

1

RS-232 ports

1

Network card slot

Yes

Battery

Battery technology

Sealed Lead Acid (VRLA)

Battery capacity

9 Ah

Battery voltage

6 V

Number of battery cells

2

Typical backup time at half load

7 min

Hot-swap battery

Yes

Design

Form factor

Rackmount

Product colour

Black, Silver

Display type

LCD

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

0 - 90%

Operating altitude

0 - 3000 m

Certificates

Waste Electrical and Electronic Equipment (WEEE) compliance

Yes

Compliance certificates

Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD), RoHS

Certification

IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA-C22.2 CE UKCA Cm Ukr KCC cTUVus BIS

Packaging content

Rack mount kit

Yes

Cables included

USB cable

Quick installation guide

Yes

Weight & dimensions

Width

438 mm

Depth

361 mm

Height

43.2 mm

Weight

8.68 kg
