Introduction

Whole Day Playback
The MP230 boasts a duplex design 2500 mAh high-capacity Lithium-ion battery, able to sustain Bluetooth playback for up to 10 hours per charge.

* Playback time is related to volume, temperature, playlist and other factors. The values listed above are the test results from Edifier Lab.

Appealing Retro Design
Inspired by vintage radios from the 1950s and 1960s, a perfect replica of piano key buttons is complemented by a legendary palette and boutique mesh.

Stereo Sound
with a Wider Sound Field
The stereo acoustic system is composed of two 48 mm full-frequency driver units, coupled with an integrated large-size dual passive radiator; compact yet powerful.

Stay Connected
with Bluetooth 5.0
The Bluetooth 5.0 delivers faster transmission,
lower battery consumption, more effective
resistance to interference, simple connection,
and free playback.

Multiple Input Modes
Aside from Bluetooth input, other supported input sources include AUX, USB-C port and TF card.

Soothing Sound
with Wooden Enclosure
The MDF wooden enclosure is thinner than plastic and warmer to the touch than metal, allowing sound to flow tenderly into a beautiful world.

Start with a Touch
of the Piano Key Button
The exquisitely designed piano key buttons
feel smooth at your fingertips with moderate
and crisp feedback are the soul of the overall concept.

Excellence in Details
The thickened foot pads with spherical contact surfaces offer great insulation from vibration and effectively prevent heavy movements.

Loudspeakers

Number of speakers

2

Number of drivers

2

Speaker type

Full range

Driver diameter

4.8 cm

Audio

RMS rated power

20 W

Speakers RMS power

10 W

Frequency range

70 - 13000 Hz

Signal-to-Noise Ratio (SNR)

80 dB

Ports & interfaces

Connectivity technology

Wired & Wireless

Wi-Fi

N

Bluetooth

Y

Bluetooth version

5.0

USB connectivity

Y

USB connector type

USB Type-C

AUX in

Y

Design

Product design

Rectangle

Product colour

Bronze, Wood

Housing material

Wood

Volume control

Buttons

On/off switch

Y

Performance

Recommended usage

Universal

Card reader integrated

Y

Compatible memory cards

MicroSD (TransFlash)

Built-in microphone

N

FM radio

N

Remotely operated

Y

Amplifier

Amplifier

Built-in

Power

Battery type

Built-in battery

Battery capacity

2500 mAh

Weight & dimensions

Width

162 mm

Depth

84.5 mm

Height

96.5 mm

Weight

850 g
