Introduction

The enterprise notebook that’s anything but ordinary
Equip your high-producing teams with the AI-enhanced PC that delivers the power of the latest Intel Core™ processor^[2] with an NPU^[3], HP Wolf Security, and intuitive collaboration tools they need for working in the office or in a hybrid setting. The HP EliteBook 860 effectively meets the demands of multi-tasking teams across the globe.

Design

Country of origin

China

Product type

Laptop

Product colour

Silver

Form factor

Clamshell

Market positioning

Premium

Introduction year

2024

Original brand name

HP

Display

Display diagonal

40.6 cm (16")

Display resolution

1920 x 1200 pixels

Touchscreen

No

HD type

WUXGA

Panel type

IPS

LED backlight

Yes

Anti-glare screen

Yes

Display brightness

400 cd/m²

Display diagonal (metric)

40.6 cm

RGB colour space

sRGB

Colour gamut

100%

Processor

Processor manufacturer

Intel

Processor family

Intel Core Ultra 7

Processor generation

Intel® Core™ Ultra (Series 1)

Processor model

155U

Processor cores

12

Processor threads

14

Processor boost frequency

4.8 GHz

Performance cores

2

Efficient cores

8

Performance-core Max Turbo Frequency

4.8 GHz

Efficient-core Max Turbo Frequency

3.8 GHz

Performance-core base frequency

1.7 GHz

Efficient-core base frequency

1.2 GHz

Processor cache

12 MB

Processor cache type

L3

Processor base power

15 W

Maximum turbo power

57 W

Memory

Internal memory

16 GB

Internal memory type

DDR5-SDRAM

Memory clock speed

5600 MHz

Memory form factor

SO-DIMM

Memory layout (slots x size)

2 x 8 GB

Memory slots

2x SO-DIMM

Maximum internal memory

64 GB

Storage

Total storage capacity

512 GB

Storage media

SSD

Total SSDs capacity

512 GB

Number of SSDs installed

1

SSD capacity

512 GB

SSD memory type

TLC

SSD interface

PCI Express 4.0

NVMe

Yes

Optical drive type

No

Graphics

On-board graphics card

Yes

On-board GPU manufacturer

Intel

On-board graphics card model

Intel Graphics

Audio

Built-in speaker(s)

Yes

Number of built-in speakers

2

Built-in microphone

Yes

Number of microphones

2

Camera

Front camera

Yes

Front camera resolution (numeric)

5 MP

Infrared (IR) camera

Yes

Network

Top Wi-Fi standard

Wi-Fi 6E (802.11ax)

Wi-Fi standards

Wi-Fi 6E (802.11ax)

Antenna type

2x2

WLAN controller model

Intel Wi-Fi 6E AX211

WLAN controller manufacturer

Intel

Bluetooth

Yes

Bluetooth version

5.3

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

HDMI ports quantity

1

HDMI version

2.1

Thunderbolt 4 ports quantity

2

Combo headphone/mic port

Yes

USB Type-C DisplayPort Alternate Mode

Yes

USB Power Delivery

Yes

Performance

Temperature sensor

Yes

Hall sensor

Yes

Keyboard

Keyboard special features

Spritzwassergeschützt

Pointing device

Clickpad

Numeric keypad

Yes

Keyboard backlit

Yes

Spill-resistant keyboard

Yes

Input device model

HP Premium Keyboard

Security

Password protection type

BIOS, Power on, User

Fingerprint reader

Yes

Password protection

Yes

Software

Operating system installed

Windows 11 Pro

Bundled software

HP Wolf Pro Security Edition (1 year)

Brand-specific features

HP Artificial Intelligence

AI PC

HP speaker type

HP Dual Speakers

HP front camera

HP Webcam 5MP

HP segment

Business

HP GTIN (EAN/UPC)

198701561118

Battery

Battery technology

Lithium Polymer (LiPo)

Number of battery cells

3

Battery capacity

56 Wh

Power

AC adapter power

65 W

AC adapter frequency

50 - 60 Hz

AC adapter input voltage

100 - 240 V

Certificates

Compliance certificates

CE, GS mark, RoHS, VCCI

Sustainability

Sustainability compliance

Yes

Sustainability certificates

ENERGY STAR, TCO

Sustainable technologies and materials

Low halogen; Bulk packaging available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; Outside box and corrugated cushions are 100% sustainably sourced and recyclable; 60% post-consumer recycled plastic; Ocean-bound plastic in speaker enclosure(s); 65% recycled metal

Weight & dimensions

Width

358.8 mm

Depth

251.3 mm

Height (front)

9 mm

Height (rear)

1.63 cm

Weight

1.72 kg

Packaging data

Package width

69 mm

Package depth

552 mm

Package height

345 mm

Other features

Colour sensor

Yes

Manufacturer warranty

1 year (1/1/0) limited warranty includes 1 year of parts and labor. No on-site repair.

Carbon footprint

Total carbon footprint (kg of CO2e)

190

Carbon emissions, manufacturing (kg of CO2e)

159

Carbon emissions, logistics (kg of CO2e)

4

Total carbon emissions, w/o use phase (kg of CO2e)

24

Technical details

General Product Safety Regulation (GPSR) URL

https://support.hp.com/us-en/document/ish_6126692-6126777-16?openCLC=true

Logistics data

Harmonized System (HS) code

8471300000
