Display

Panel type

IPS

Display diagonal

163.8 cm (64.5")

Display technology

LED

Display resolution

3840 x 2160 pixels

Display brightness

800 cd/m²

HD type

4K Ultra HD

Touchscreen

No

Native aspect ratio

16:9

Response time

8 ms

Contrast ratio (typical)

1200:1

Viewing angle, horizontal

178°

Viewing angle, vertical

178°

Display number of colours

1.07 billion colours

Pixel pitch

0.372 x 0.372 mm

Active display area (W x H)

803.52 x 680.72 mm

Display diagonal (metric)

163.9 cm

Horizontal scan range

28 - 160 kHz

Native refresh rate

60 Hz

Haze rate

1%

RGB colour space

NTSC

Ports & interfaces

HDMI ports quantity

2

HDMI version

2.0

DisplayPorts quantity

1

DisplayPort version

1.2

USB port

Yes

USB ports quantity

2

USB version

2.0

Ethernet LAN

Yes

Ethernet LAN (RJ-45) ports

1

Wi-Fi

Yes

Wi-Fi standards

Wi-Fi 5 (802.11ac)

Audio (L/R) in

1

RS-232 interface

Yes

RS-232C

Yes

Audio

Built-in speaker(s)

Yes

Number of built-in speakers

2

RMS rated power

20 W

Design

Product design

Kiosk design

Orientation

Horizontal/Vertical

Product colour

Black

VESA mounting

Yes

Panel mounting interface

400 x 400 mm

Bezel width (bottom)

1.49 cm

Bezel width (side)

1.49 cm

Bezel width (top)

1.49 cm

Bezel colour

black

Performance

Purpose

Commercial

Number of OSD languages

8

On Screen Display (OSD) languages

Simplified Chinese, Czech, German, English, Spanish, French, Italian, Japanese, Polish, Russian

Operating hours (hours/days)

24/7

HDCP

Yes

HDCP version

2.2

Mean time between failures (MTBF)

50000 h

Power

Power consumption (typical)

104 W

Power consumption (standby)

0.5 W

Power consumption (off)

0.3 W

Energy efficiency class (SDR)

E

Energy consumption (SDR) per 1000 hours

104 kWh

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

Energy efficiency scale

A to G

Computer system

Computer system

Yes

Built-in processor

Yes

Processor manufacturer

ARM

Processor family

ARM Cortex

Processor architecture

ARM Cortex-A53+Cortex-A73

Processor cores

8

Internal memory

4 GB

On-board graphics card model

ARM Mali-G52

Internal storage capacity

32 GB

Operating system installed

Android 11

Weight & dimensions

Display width

1456.5 mm

Display depth

56 mm

Display height

832.5 mm

Display weight

20.7 kg

Packaging data

Package width

1345 mm

Package depth

162 mm

Package height

1016 mm

Package weight

28.7 kg

Packaging content

Remote control included

Yes

Cables included

HDMI, Power, RS-232

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

-20 - 60%
