Model & OS

Model

ZBook Studio G9

Installed OS

Windows® 11 Pro

Processor

Processor Type

Intel®

Processor Speed

Core™ i7-12700H 2.30 GHz

Processor Cache

24 MB L3 cache

Security

Fingerprint Reader

Yes

Memory

Memory Type

DDR5

Memory Std.

16 GB

Memory Speed

4800 MHz

Memory Slots

2 x SODIMM; supports dual channel

Drives / Storage

SSD Capacity

512 GB

Display

Display Type

IPS, anti-glare

LED backlight

Yes

Display Size

16 inches

Display Max. Res.

1920 x 1200

Multimedia

Integrated Camera

HP HD IR Camera 720p with face authentication and Windows Hello

Graphics

Graphic Controller

Intel® Iris® Xe Graphics

RAM Capacity

4 GB

Audio

Audio

Audio by Bang & Olufsen

Integrated Speakers

Quad-speaker audio (2 tweeters & 2 Quad woofers)

Audio Details

HD audio with 200Hz Bass Roll off

Built in Mic

2 x Top Facing Microphone dual array digital microphones, functions keys for volume up and down, combo microphone/headphone jack

Interfaces

Ports - USB 3 Series Type-A

1 x Super Speed USB Type-A 5Gbps signaling rate (charging

Ports - USB Type-C

1 x SuperSpeed USB Type-C® 10Gbps signaling rate (USB Power Delivery, DisplayPort 1.4)

Ports - Audio

1 x headphone/microphone combo

Ports - Other

1 x power connector

Thunderbolt

2 x Thunderbolt 4 with USB4 Type-C® 40Gbps signaling rate (USB Power Delivery, DisplayPort 1.4, HP Sleep and Charge)

Slots / Expansions

Card Reader

1 microSD 7.1 media card reader

Connectivity

WLAN

Intel® Wi-Fi 6E AX211 (2x2)

Bluetooth

Bluetooth® 5.2 combo

Input

Backlit

Yes

Spill-resistant

Yes

Power

Battery Type

Li-ion polymer

Battery Capacity

86 Wh

Ac Adaptor

200 W Slim Smart external AC power adapter

Number Of Cells

6

Dimensions

Width

35.6 cm (14.02 inches)

Height

1.9 cm (0.75 inches)

Depth

24.2 cm (9.53 inches)

Weight

1.73 kg (3.81 lb)

Green Certificates

Energy Star Certified

Yes

Epeat

Gold

Green Compliant

Yes

TCO

TCO 9
